High Quality ST-260 Plastic Chair Injection Molding Machine

SINO-TECH injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. Machine with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Quantity:
whatsapp sharing button
wechat sharing button
sharethis sharing button
  • ST-260

  • SINOTECH

  • 8474809090

  • 70mm

  • 52.9g/s

  • 1210mm

  • 260Ton

  • 26.7kW

  • 63.7A

  • 8.55Ton

  • 480L

Injection detail1

We use a new generation of upgraded high-performance injection molding machines:
01-Opening Stroke
Increased by up to 15%
02-Ejector stroke
Increased by up to 20%
03-Mould thickness
Increased by up to 15%
04-Max. Daylight
Increased by up to 55%
05-Ejector Force
Increased by up to 40%

The injection molding machine uses Sellll upgraded components to achieve additional durability through an optimized clamping structure, a new and optimized injection unit design to meet various production needs, and uses an efficient and stable servo hydraulic system and high-performance European B&R control system.

Features
01-30% higher energy saving than using traditional variable pump
02-Stable and smooth movement supported by AC servo motor
03-Effective reduction of energy consumption due to reduced oil and cooling water attained by hydraulic system
04-High performance European B&R control system

Item
260SElll
Screw diameter mm 55 60 70
Theoretical shot volume cc 713 848 1155
Shot weight (PS) g 649 772 1051
Shot weight (PS) oz 22.9 27.3 37.1
Length/Diameter ratio L/D 22.9 21 18
Injection pressure MPa 211 178 131
Injection rate cm⊃3;/sec 237 282 384
Injection stroke mm 300
Max. Screw speed rpm 175
Plasticizing capacity (PS) g/s 32.3 35.2 52.9
Injection unit force Ton 9.1
Carriage stroke mm 350
Clamping force Ton 260
Max. daylight mm 1210
Clamping stroke mm 600
Distance btwn. Tie bars mm 580*580
Min mould dimension mm 400*400
Mould thickness range mm 195-610
Ejector force Ton 11.1
Ejector stroke mm 180
No. of ejector pins unit 13
Max. motor power kW 26.7
System pressure MPa 17.5
Hydraulic pump capacity L/min 172
No. of heater zones unit 5+1
Heater input power kW 18.9
Ultimate capacity kw 46.6
Current A 63.7
Net weight Ton 8.55
Oil filling capacity L 480
