Over 20 years' Experience With Automatic Blow Molding Machine
Email us : sales@sinotechmachine.com
 |
| Quantity: | |
|---|---|
ST-750
SINOTECH
8474809090
110mm
121g/s
440L/min
2050mm
1025mm
83.8kW
132.8kw
| Item | Unit | 750SElll | ||
| Screw diameter | mm | 90 | 100 | 110 |
| Theoretical shot volume | cc | 2990 | 3691 | 4467 |
| Shot weight (PS) | g | 2691 | 3322 | 4020 |
| Shot weight (PS) | oz | 95 | 117 | 142 |
| Length/Diameter ratio | L/D | 22.6 | 20.0 | 18.0 |
| Injection pressure | MPa | 212 | 171 | 142 |
| Injection rate | cm⊃3;/sec | 572 | 706 | 854 |
| Plasticizing capacity(PS) | G/s | 73 | 90 | 121 |
| Injection stroke | mm | 470 | ||
| Max. Screw speed | rpm | 124 | ||
| Injection unit force | Ton | 19.8 | ||
| Carriage stroke | mm | 600 | ||
| Clamping force | Ton | 750 | ||
| Max. daylight | mm | 2050 | ||
| Clamping stroke | mm | 1025 | ||
| Distance btwn. Tie bars | mm | 1000*1000 | ||
| Min mould dimension | mm | 700*700 | ||
| Mould thickness range | mm | 350-1025 | ||
| Ejector force | Ton | 25 | ||
| Ejector stroke | mm | 350 | ||
| No. of ejector pins | unit | 21 | ||
| Max. motor power | kW | 83.8 | ||
| System pressure | MPa | 17 | ||
| Hydraulic pump capacity | L/min | 440 | ||
| No. of heater zones | unit | 5+1 | ||
| Heater input power | kW | 50 | ||
| Ultimate capacity | kw | 132.8 | ||
| Current | A | 161.4 | ||
| Net weight | Ton | 39.1 | ||
| Oil filling capacity | L | 1500 | ||
