ST-500
SINOTECH
8474809090
94mm
131.3g/s
275L/min
1700mm
850mm
50.7kW
86.64kw
| Item | | 500SElll | ||
| Screw diameter | mm | 70 | 80 | 94 |
| Theoretical shot volume | cc | 1539 | 2011 | 2776 |
| Shot weight (PS) | g | 1401 | 1830 | 2526 |
| Shot weight (PS) | oz | 49.5 | 64.7 | 89.3 |
| Length/Diameter ratio | L/D | 24.2 | 21.2 | 18 |
| Injection pressure | MPa | 228 | 174 | 126 |
| Injection rate | cm⊃3;/sec | 352 | 460 | 635 |
| Injection stroke | mm | 400 | ||
| Max. Screw speed | rpm | | ||
| Plasticizing capacity (PS) | g/s | 72.7 | 94.3 | 131.3 |
| Injection unit force | Ton | 12 | ||
| Carriage stroke | mm | 480 | ||
| Clamping force | Ton | 500 | ||
| Max. daylight | mm | 1700 | ||
| Clamping stroke | mm | 850 | ||
| Distance btwn. Tie bars | mm | 840*830 | ||
| Min mould dimension | mm | 580*580 | ||
| Mould thickness range | mm | 300-850 | ||
| Ejector force | Ton | 16.6 | ||
| Ejector stroke | mm | 240 | ||
| No. of ejector pins | unit | 17 | ||
| Max. motor power | kW | 50.7 | ||
| System pressure | MPa | 17.5 | ||
| Hydraulic pump capacity | L/min | 275 | ||
| No. of heater zones | unit | 5+1 | ||
| Heater input power | kW | 34.94 | ||
| Ultimate capacity | kw | 86.64 | ||
| Current | A | 118.5 | ||
| Net weight | Ton | 18.66 | ||
| Oil filling capacity | L | 700 | ||
