ST-1000JSell
SINOTECH
8474809090
125mm
154g/s
115rpm
490mm
105.2kW
17.5 22.1MPa
197.2A
45.5Ton
| Item | | 1000JSell | ||
| Screw diameter | mm | 100 | 110 | 125 |
| Theoretical shot volume | cm⊃3; | 3848 | 4657 | 6013 |
| Shot weight (PS) | g | 3646 | 4191 | 5412 |
| Length/Diameter ratio | L/D | 22.3 | 20.0 | 17.7 |
| Injection pressure(high pressure and low speed) | MPa | 215 | 178 | 138 |
| Injection pressure(low pressure and high speed | MPa | 156 | 129 | 100 |
| Injection rate(high pressure and low speed) | cm⊃3;/sec | 671 | 812 | 1048 |
| Injection rate(low pressure and high speed) | cm⊃3;/sec | 925 | 1119 | 1445 |
| Plasticizing capacity (PS) | g/s | 93 | 118 | 154 |
| Injection stroke | mm | 490 | ||
| Screw speed | rpm | 115 | ||
| Injection unit force | Ton | 20.0 | ||
| Carriage stroke | mm | 920 | ||
| Clamping force | Ton | 1000 | ||
| Opening force | Ton | 106.1 | ||
| Opening force | Ton | 34.7 | ||
| Max. daylight | mm | 2400 | ||
| Clamping stroke | mm | 1200-1800 | ||
| Distance btwn. Tie bars | mm | 1210*1060 | ||
| Min mould dimension | mm | 840*740 | ||
| Mould thickness range | mm | 600-1200 | ||
| Ejector force | Ton | 21.5 | ||
| Ejector stroke | mm | 300 | ||
| No. of ejector pins | unit | 21 | ||
| Dry Cycle(Euromap 6) | S | 5.7 | ||
| Major motor | kW | 105.2 | ||
| System pressure | MPa | 17.5 22.1 | ||
| No. of heater zones | unit | 5+1 | ||
| Heater input power | kW | 56 | ||
| Ultimate capacity | kw | 162.2 | ||
| Current | A | 197.2 | ||
| Net weight | Ton | 45.5 | ||
| Oil filling capacity | L | 1800 | ||
