ST-200SElll
SINOTECH
8474809090
The 5 Gallon Water Bottle Cap Injecting Making Machine is engineered to produce high-quality, durable caps for 5-gallon water bottles. With its advanced injection molding technology, this machine ensures high precision and fast production cycles, making it ideal for businesses in the bottling and beverage industries. Its energy-efficient operation and low maintenance make it a perfect solution for high-volume production needs, ensuring that businesses can meet the growing demand for water bottle caps.
Designed for efficiency, this machine not only produces caps with consistent quality but also minimizes energy consumption, providing an eco-friendly solution for manufacturers.
High-Precision Molding: The machine’s advanced injection molding system ensures that each water bottle cap is molded with high precision, reducing defects and waste.
Fast and Energy-Efficient Production: With a servo-driven system, the machine minimizes energy consumption while ensuring high-speed production, making it an eco-friendly and cost-effective choice for manufacturers.
Optimized for High-Volume Production: This machine is capable of producing a large number of water bottle caps in a short amount of time, making it perfect for bottling plants and distributors with high production demands.
Cost Savings: The machine is designed to lower energy costs while ensuring consistent and high-quality cap production, providing excellent ROI for businesses.
| Item | 200SElll | |||
| Screw diameter | mm | 45 | 50 | 60 |
| Theoretical shot volume | cc | 398 | 491 | 707 |
| Shot weight (PS) | g | 362 | 447 | 643 |
| Shot weight (PS) | oz | 12.8 | 15.8 | 22.7 |
| Length/Diameter ratio | L/D | 24 | 21.6 | 18 |
| Injection pressure | MPa | 219 | 177 | 123 |
| Injection rate | cm³/sec | 150 | 185 | 266 |
| Injection stroke | mm | 250 | ||
| Max. Screw speed | rpm | 185 | ||
| Plasticizing capacity (PS) | g/s | 22.5 | 28 | 34.2 |
| Injection unit force | Ton | 9.1 | ||
| Carriage stroke | mm | 350 | ||
| Clamping force | Ton | 200 | ||
| Max. daylight | mm | 1090 | ||
| Clamping stroke | mm | 540 | ||
| Distance btwn. Tie bars | mm | 535*535 | ||
| Min mould dimension | mm | 370*370 | ||
| Mould thickness range | mm | 175-550 | ||
| Ejector force | Ton | 7.7 | ||
| Ejector stroke | mm | 150 | ||
| No. of ejector pins | unit | 9 | ||
| Max. motor power | kW | 16.4 | ||
| System pressure | MPa | 17.5 | ||
| Hydraulic pump capacity | L/min | 112.5 | ||
This machine is primarily used for producing caps for 5-gallon water bottles, a critical component for the bottled water industry. It ensures that the caps are produced with precision and reliability, meeting industry standards for safety and quality.
SINOTECH’s injection molding machines are known for their precision and energy efficiency. With over 20 years of experience, we offer robust solutions that help businesses streamline production while keeping costs low.
The 5 Gallon Water Bottle Cap Injecting Making Machine is engineered to produce high-quality, durable caps for 5-gallon water bottles. With its advanced injection molding technology, this machine ensures high precision and fast production cycles, making it ideal for businesses in the bottling and beverage industries. Its energy-efficient operation and low maintenance make it a perfect solution for high-volume production needs, ensuring that businesses can meet the growing demand for water bottle caps.
Designed for efficiency, this machine not only produces caps with consistent quality but also minimizes energy consumption, providing an eco-friendly solution for manufacturers.
High-Precision Molding: The machine’s advanced injection molding system ensures that each water bottle cap is molded with high precision, reducing defects and waste.
Fast and Energy-Efficient Production: With a servo-driven system, the machine minimizes energy consumption while ensuring high-speed production, making it an eco-friendly and cost-effective choice for manufacturers.
Optimized for High-Volume Production: This machine is capable of producing a large number of water bottle caps in a short amount of time, making it perfect for bottling plants and distributors with high production demands.
Cost Savings: The machine is designed to lower energy costs while ensuring consistent and high-quality cap production, providing excellent ROI for businesses.
| Item | 200SElll | |||
| Screw diameter | mm | 45 | 50 | 60 |
| Theoretical shot volume | cc | 398 | 491 | 707 |
| Shot weight (PS) | g | 362 | 447 | 643 |
| Shot weight (PS) | oz | 12.8 | 15.8 | 22.7 |
| Length/Diameter ratio | L/D | 24 | 21.6 | 18 |
| Injection pressure | MPa | 219 | 177 | 123 |
| Injection rate | cm³/sec | 150 | 185 | 266 |
| Injection stroke | mm | 250 | ||
| Max. Screw speed | rpm | 185 | ||
| Plasticizing capacity (PS) | g/s | 22.5 | 28 | 34.2 |
| Injection unit force | Ton | 9.1 | ||
| Carriage stroke | mm | 350 | ||
| Clamping force | Ton | 200 | ||
| Max. daylight | mm | 1090 | ||
| Clamping stroke | mm | 540 | ||
| Distance btwn. Tie bars | mm | 535*535 | ||
| Min mould dimension | mm | 370*370 | ||
| Mould thickness range | mm | 175-550 | ||
| Ejector force | Ton | 7.7 | ||
| Ejector stroke | mm | 150 | ||
| No. of ejector pins | unit | 9 | ||
| Max. motor power | kW | 16.4 | ||
| System pressure | MPa | 17.5 | ||
| Hydraulic pump capacity | L/min | 112.5 | ||
This machine is primarily used for producing caps for 5-gallon water bottles, a critical component for the bottled water industry. It ensures that the caps are produced with precision and reliability, meeting industry standards for safety and quality.
SINOTECH’s injection molding machines are known for their precision and energy efficiency. With over 20 years of experience, we offer robust solutions that help businesses streamline production while keeping costs low.
