High speed 5L 10L 20L 25L 30L plastic bottles bucket barrel blow molding moulding making Machine
1. Suitable products
5-30L PE, HDPE, PP bottles
Applications: milk/ yogurt bottles, food pack containers, plastic jars, chemical bottles, cosmetic bottles, lubricant oil bottles, household bottles, detergent bottles, shampoo bottles, oil bottles,jerry cans,lubricate cans...
2. Station
The machine is double station single head, cycle time70-80s,
per hour can make 90-110pcs bottles, and per day can make 2160-2640pcs bottles,
If customers do not need this much production, we also have single station single head machine, per day it can make 3600pcs.
( our engineers will make complete solutions according to customers bottle and capacity demands.)
3. Die head
This machine is using single die head to make 10~30L barrels,
However, the die head can also be changed to double die head, triple die head and 4 head to be able to make other smaller size bottles.
Single die head (10~30L)
Double die head (5~10L)
Triple die head (1~3ml)
Four die head (0~1000ml)
Changing the die head system takes around 1.5~3h, this also included heating time.
4.Mould - Aluminium 7075# inserted beryllium copper or 4Cr13 stainless material
the best blow molding mould material, aluminium mould has good cooling, and beryllium copper is very durable as well.
4Cr13 moul materal is good strength with longlife time use.
5.Parison control system is a program to change the parison thickness,As the plastic is extruded from the die head,the programming can:
1. Reduce the plastic used
2. Improved wall thickness distribution
3. Reduce cooling time
Do we have to use MOOG parison system?
No, We also have many customers they do not use MOOG parison control system, as on our machine's die head, we also can manually adjust the die gaps, from which it can also control the thickness and weight of bottles.
MOOG is more precision, and more easy to do the adjust. It also depends on your ending customer demands and markets.
But for some special designed blow molding items & accumulation type blow molding machines,MOOG is indispensable, it has to use MOOG.
FAQ:
Q: Can we visit your factory?
Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong
International Airport. We can pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by
video.
Q: How can we get the exact price of plastic machine?
Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with
quotation.
Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.(contact us for packing list )
Q: How about your after-sale service ?
We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical
support or field installation assist.
Q: What is the lead time?
For customized machine, it takes about 45-60 days after deposit. For stock machine, fast shipment. ( The actual production cycle
will vary according to the degree of customization.)
Q: What is the warranty period for your machine ?
12 months warranty for components and technical support .
Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers
products to meet customer' needs.
Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the
customer's employees.
Q: What's the advantage of SINOTECH?
We provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can
source the auxiliary equipments for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.
